ChemSet™ Anchor Studs
ChemSet Anchor Studs are made from quality Grade 5.8 carbon steel to get the most out of adhesive tensile capacities and provide higher shear capacities than regular Grade 4.6 grade studs. Galvanising of ChemSet Anchor Studs meets Australian Standards. Stainless Steel ChemSet Anchor Studs are high corrosion resistant AISI 316 (A4).
Material
- Galvanised
- Stainless Steel
- Zinc Plated
Thread Size
- M8
- M10
- M12
- M16
- M20
- M24
Length (mm)
- 110
- 130
- 160
- 180
- 190
- 260
- 300
Before visiting a Stockist or Service Centre, contact them to ensure product availability.
PART NUMBER:
ChemSet™ Anchor Studs
-+PRODUCT INFORMATION
Click on the column headings to reorder the table.
| ITEM CODE | Material | Thread Size | Length (mm) | Drill Size (mm) | Drill Depth (mm) | Environment | QTY | ADD TO TOOLBOX |
|---|---|---|---|---|---|---|---|---|
| CS12180 |  | M12 | 180 | 14 | 110 | Indoor | 10 | |
| CS20260 | | M20 | 260 | 22 | 150 | Indoor | 6 | |
| CS24300 | | M24 | 300 | 26 | 160 | Indoor | 6 | |
| CS16190 | | M16 | 190 | 18 | 125 | Indoor | 10 | |
| CS12160 | | M12 | 160 | 14 | 110 | Indoor | 10 | |
| CS10130 | | M10 | 130 | 12 | 90 | Indoor | 10 | |
| CS08110 | | M8 | 110 | 10 | 80 | Indoor | 10 | |
| CS24300SS |  | M24 | 300 | 26 | 160 | Coastal | 6 | |
| CS20260SS | | M20 | 260 | 22 | 150 | Coastal | 6 | |
| CS16190SS | | M16 | 190 | 18 | 125 | Coastal | 10 | |
| CS12160SS | | M12 | 160 | 14 | 110 | Coastal | 10 | |
| CS08110SS | | M8 | 110 | 10 | 80 | Coastal | 10 | |
| CS10130SS | | M10 | 130 | 12 | 90 | Coastal | 10 | |
| CS24300GH |  | M24 | 300 | 26 | 160 | Outdoor | 6 | |
| CS20260GH | | M20 | 260 | 22 | 150 | Outdoor | 6 | |
| CS16190GH | | M16 | 190 | 18 | 125 | Outdoor | 10 | |
| CS12160GH | | M12 | 160 | 14 | 110 | Outdoor | 10 | |
| CS10130GH | | M10 | 130 | 12 | 90 | Outdoor | 10 | |
| CS08110GH | | M8 | 110 | 10 | 80 | Outdoor | 10 |
STEEL ZINC PLATED
STAINLESS STEEL
GALVANISED STEEL
-+FEATURES & BENEFITS
- High Performance Grade 5.8 Carbon Steel
- Zinc Plated for indoor or dry climates
- Hot dip galvanised to AS1650 and AS1214
- Hot dip galvanised to 42 micron for exterior applications
- High Performance AISI316 Stainless Steel for Coastal Applications
- Pre-cut to standard chemical anchoring lengths
- Depth set mark to ensure correct embedment
- Reliable external hex drive for installing capsules
- Chisel-ended to prevent unthreading
-+APPLICATIONS & TRADES
| Anchoring structural steel column/beams | Steel Fabricator |
|---|---|
| Machinery hold down | Maintenance Fitter |
| Installing handrails, balustrades & safety barriers | Steel Fabricator, Fencing Contractor |
| Public Seating | Seating Contractor |
| Timber Frame Hold Down | Carpenter |
| Pipe & cable tray installation | Plumbing Contractor, Electrical Contractor |
-+SPECIFICATIONS
| Material | Bolt Carbon Steel, Stainless Steel 316 (A4) |
|---|---|
| Corrosion Protection | Zinc Plating, Hot Dipped Galvanising |
| Head Styles | Hex Nut |
| Fixing Method | Through Fixture |
| Setting Method | Chemical |
| Anchoring Method | Chemical |
| Thread Diameters | M8, M10, M12, M16, M20, M24 |
| Anchor/Hole Diameters | 10mm, 12mm, 14mm, 18mm, 24mm, 26mm Anchor Lengths 110mm, 130mm, 160mm, 190mm, 260mm, 300mm |
| Anchor Lengths | 110mm, 130mm, 160mm, 190mm, 260mm, 300mm |
| Maximum Fixture Thickness | 15mm, 25mm, 30mm, 50mm, 40mm, 45mm, 80mm, 90mm, 105mm |
| Substrates | Concrete, Solid Brickwork |
